规格 |
A |
C |
E |
F1 |
G |
H |
I |
J |
L |
L4 |
L5 |
L7 |
N |
O |
P |
Q |
R |
S |
T |
U |
|
10 |
R3/8 |
Rc3/8 |
79 |
40 |
8 |
55 |
14 |
34 |
164 |
149 |
36 |
16 |
10 |
22 |
60 |
90 |
14 |
8 |
4 |
14 |
|
15 |
R1-2 |
Rc1/2 |
79 |
40 |
8 |
55 |
14 |
34 |
175 185 |
158 170 |
42 57 |
20 |
14 |
26 |
65 |
95 |
14 |
8 |
4 |
14 |
|
20 |
R3/4 |
Rc3/4 |
89 |
45 |
10 |
65 |
14 |
38 |
97 201 |
177 181 |
45 49 |
22 |
18 |
29 |
75 |
105 |
16 |
8 |
4 |
14 |
|
25 |
R1 |
Rc1 |
110 |
55 |
10 |
70 |
14 |
40 |
256 257 |
231 232 |
63 64 |
25 |
25 |
40 |
85 |
115 |
16 |
10 |
4 |
14 |
|
32 |
R1-1/4 |
Rc1-1/4 |
119 |
78 |
10 |
82 |
18 |
48 |
264 266 |
234 236 |
58 60 |
28 |
32 |
44 |
100 |
140 |
18 |
12 |
4 |
18 |
|
40 |
R1-1/2 |
Rc1-1/2 |
125 |
83 |
10 |
92 |
20 |
50 |
288 299 |
256 267 |
60 71 |
30 |
33 |
49 |
110 |
150 |
18 |
12 |
4 |
18 |
|
50 |
R2 |
Rc2 |
167 |
88 |
10 |
95 |
20 |
50 |
308 320 |
270 282 |
56 68 |
32 |
50 |
60 |
125 |
165 |
20 |
15 |
4 |
18 |
|
65 |
R2-1/2 |
Rc2-1/2 |
186 |
110 |
14 |
120 |
20 |
50 |
359 359 |
314 314 |
72 72 |
42 |
65 |
75 |
145 |
185 |
20 |
18 |
4 |
18 |
|
80 |
R3 |
Rc3 |
207 |
115 |
16 |
130 |
24 |
54 |
390 |
334 |
80 |
45 |
75 |
90 |
160 |
200 |
20 |
20 |
8 |
18 |
|
