结构特点: 此系列采用平衡式密封结构,主要为冷却系统而设计的,具有体积小、重量轻、摩擦转距小等优点,适用于较高转速环境。 使用条件: 适用介质:水、热水、空气、冷却液 最高转速:1000rpm(标准型)4000rpm(高速型) 最高温度:120℃(标准型)260℃(高温型) 最高压力:1.8Mpa(标准型)30Mpa(高压型)
Structure feature Balanced sealing structure is adopted for this series , maily de –signde for cooling water .lt is of small size, light weight and it is bet-ter used in high speed atmosphere . Usage condition Suitable Medium: Water ,heat water ,air ,cooling liquid Max. Speed : 1000rpm(standard),4000rpm(high speed) Max. Temperature :120℃(standard)260℃(high temperature)
Max.Pressure:1.8Mpa(standard)30Mpa(high pressure)
|
